IO INDUSTRIES - Camera and Accessory Kit for Flare 4KSDI with Passive EF Lens Mount (EU)

Variations
Logo Io Industries
€ 7.995,00 excl. VAT
€ 9.594,00 incl. VAT

Free shipping to

Andorra, Austria, Belgium, Bulgaria, Croatia, Cyprus, Czech Republic, Denmark, Estonia, Finland, France, French Guiana, French Polynesia, Germany, Greece, Guadeloupe, Hungaria, Ireland, Italy, Lettland, Lichtenstein, Litauen, Luxemburg, Malta, Martinique, Mayotte, Netherlands, New Caledonia, Norway, Poland, Portugal, Reunion, Romania, Saint-Barthélémy, Saint-Martin, Saint-Pierre and Miquelon, Slovakia, Slovenia, Spain, Sweden, Switzerland, United Kingdom, Wallis-et-Futuna


Usually ships within 7-10 days

This item is out of stock. If you want to be kept up to date when it's back in stock, click on the button below.

Choose your options

Mount

Description

Introducing the IO Industries Flare 4KSDI - the first compact 4K/UHD camera head designed to fit where larger cameras cannot.

But despite its size, this small form factor camera has the capability to deliver the high-quality imagery demanded by industry
professionals. The extensive feature set makes the 4KSDI easy to deploy in either live event broadcasts or scripted productions.

The tough aluminum chassis includes rugged mounting points on all sides, proving it really can be placed anywhere.
Multiple interchangeable lens mounts are available including Arri PL, Nikon F and Canon EF, allowing a range of familiar lenses to be used. In addition, an integrated Optical Low Pass Filter helps block IR pollution and remove moiré artifacts. At the heart of the camera sits a Super 35 global shutter CMOS sensor with 12 stops of dynamic range. Four standard 3G/HD-SDI outputs make connecting the 4KSDI to peripheral devices easy. Depending on the output format, either two or four cables are needed to connect the 4KSDI to a growing selection of 4K/UHD-supported field recorders, monitors, and live production switchers. And, for stereoscopic or panoramic configurations, or live-to-air broadcasts, an HD tri-level sync reference is all that’s needed for precise multi-camera synchronization.

With the Flare 4KSDI, the power of 4K video can truly fit in the palm of your hand.

Included

Whats in the box
What's in the box
4KSDI Camera Head
Power Cable / Cable
AC-DC Adapter EU (ACPWRTAP)
USB Cable
2m USB control cable / PC control interface (CABUSB4852M)
Cable(s)
Power/ control cable / Lemo, D-Tap, Hirose (CABFLAREBATT)
Accessories
Handheld remote
Controls OSD

Technical features

Sensor and Optical
Sensor Type
Global Shutter CMOS
Sensor Size
Super 35 (22.53 x 11.88mm)
Dynamic Range
12 stops
Integrated Filter
IR-Cut and OLPF
Connections
SDI Video Output
• 4x 3G/HD-SDI (4x BNC)
Color Science
Neutral / White Balance
• Manual
• Temperature Presets
• 1-Shot Auto
• Tracking Auto
Color Correction
• Matrix Adjustment
• Saturation
Gamma
• Rec. 709, Cine Log
• Black Gamma
Custom LUT
• (6) RGB LUTs
• (4) RAW LUTs
Exposure / Shutter Control
• Manual
• Automatic
Sensitivity Adjustment
• ISO control
• Up to 4x digital gain
Level Control
• Master Pedestal
• Knee Level and Slope
Power
Power Draw
7-19V DC (10W max.)
Operating Temperature
• Recommended operation: -30°C to 40°C
• Storage: -30°C to 60°C
Inputs/Outputs
Quad-Link Formats
10-bit 4:2:2 or RAW
• UHD 23.98, 24, 25, 29.97, 30, 50, 59.94, 60
• 4K 23.98, 24, 25, 29.97, 30, 47.95, 48, 50, 59.94, 60
10-bit 4:4:4
• UHD 23.98, 24, 25, 29.97, 30
• 4K 23.98, 24, 25, 29.97, 30
Dual-Link Formats
10-bit 4:2:2 or RAW
• UHD 23.98, 24, 25, 29.97, 30
• 4K 23.98, 24, 25, 29.97, 30
